How Sigma Kneader Works?

How Sigma Kneader Works

SIGMA KNEADER
consist of double “U” shaped container made of either Mild Steel or Stainless Steel 304 or 316 with jacket of Carbon Steel covering two side for heating or cooling application & dust free cover to accomplish vacuum if desired or normal cover.

The mixing elements are two nos. Z type steel casted blades.. They contra rotate inward fitted at close
or specified clearance with the container to give thorough and uniform mixing. There
is a gland pusher of gun metal bush which ensure minimal friction and extend the life
of mixing elements (Blades). Two counter rotating mixing arms rotate at different speeds (usually
in the ratio of 3 to 2) in the trough, the intersection of which forms a saddle and the
arms meet tangentially just above the saddle.

The mixing action is a combination of bulk movement, shearing, stretching, folding, dividing, and recombining as the material
is pulled and squeezed against blades, saddle, and side walls. Continually new layers of material are compressed and folded over one another and
are subjected to shearing forces. New surfaces are formed and the components can penetrate. The blades, which are ground and polished, successively
sweep all points of the trough surface during each revolution, at the same time dividing the batch continuously across the saddle piece and
thereby achieving a perfect mix.

“DUPLEX” Kneader

Duplex kneaders are twin basin kneaders with two horizontally arranged kneading blades, which are deeply geared into one another and strip themselves reciprocally. The kneading blades are turning to a ratio of 1:2. Because  of their different speeds, the blade sides approach and withdraw alternately.

This causes high pressure tensile and shearing rates and therefore heavy friction  in the kneading medium, which creates excellent dispersing and homogeneity. The shape of the kneading blades enables a steady flow of material from the side walls of the kneading trough to the middle of the trough.

Apart from the sigma blades, we also offer sigma disperser blades



Different types of Sigma Blade Available



Sigma- or Z-form blade

Sigma- or Z-form blade

two_wing_blade

two_wing_blade

Double naben

Double naben Sigma Blade
